Corten Steel Plate
Trident Enterprises are among the pre-eminent organizations, involved in manufacturers, suppliers, stockists and exporter Cor ten Steel Plate. Available in different lengths, thicknesses and sizes, these Cor ten Steel Plate are widely demanded by various industries like food & beverage, chemical, petrochemical, pharmaceutical and cosmetics. In addition to this, we provide tailor-made solution for all our offered Cor ten Steel Plate as per customers’ requirements.
What is Corten?
Weathering steel, best-known under the trademark COR-TEN steel and sometimes written without the hyphen as "Corten steel", is a group of steel alloys which were developed to eliminate the need for painting, and form a stable rust-like appearance if exposed to the weather for several years.U.S. Steel holds the registered trademark on the name COR-TEN.Although USS sold its discrete plate business to International Steel Group (now Arcelor-Mittal) in 2003,it still sells COR-TEN branded material in strip-mill plate and sheet forms.
The original COR-TEN received the standard designation A 242 ("COR-TEN A") from the ASTM International standards group. Newer ASTM grades are A 588 ("COR-TEN B") and A 606 for thin sheet. All alloys are in common production and use.
We are an ISO 9001:2008,ISO 9001-2008, ISO 14001-2004, OHSAS 18001-2007, NSIC-CRISIL, EEPC, and QA-UKAS (ISO 9001-2008), SSI Certified company that follows total Quality Management System. and have been recognized as one of the world’s leading stockists and manufacturer of quality metals for over two decades and are committed to quick responses, unsurpassed quality, competitive pricing, reliable deliveries and an exhaustive inventory.
| Type | Cor ten Steel Plate |
| Standard | ASTM A588, A242 |
| Grade | IRSM-41, Corten A ,Corten B , S355J0WP , S355J0W, S355J2W , A588 Grade A, A588 Grade B, A588 Grade C , A242 Type 1 , SA588 Grade A, SA588 Grade B, SA588 Grade C |
| Thickness | 0.3-500mm |
| Width | 10-3500mm |
| Length | 2m, 2.44m, 3m, 6m, 8m, 12m or rolled etc |
| Delivery time | up to the order quantity |
| Order | Accept custom order |
| Quality Assurance | They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions and quality conformity of products. |
| Marking & Packing | Products are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases.On special requests we can also, make custom marking on our products. |
| Application |
|
| Test Certificates | Manufacturer Test Certificate / Laboratory Test Certificate from Govt. Approved Lab. / Under Third Party Inspection with Excise Gate Pass to available benefit. |
Corten Steel Can Be Also Supplied According To Following Standard & Specifications
| COR-TEN® A, COR-TEN®A, COR-TEN A, CORTEN-A, CORTEN A |
| COR-TEN® B, COR-TEN®B, COR-TEN B, CORTEN-B, CORTEN B |
| ASTM A588 Grade A, ASTM A 588 Grade-A, ASTM A-588 Grade A |
| ASTM A588 Grade B, ASTM A 588 Grade-B, ASTM A-588 Grade B |
| ASTM A588 Grade C, ASTM A 588 Grade-C, ASTM A-588 Grade C |
| ASTM A242 Type 1, ASTM A242 Type-1, ASTM A-242 Type 1 |
| S355JOWP EN 10025-5, S355JOWP EN10025-5, S355 JOWP EN-10025-5 |
| S355JOWP+N EN 10025-5, S355JOWP+N EN10025-5, S355 JOWP+N EN-10025-5 |
| S355J2W EN 10025-5, S355J2W EN10025-5, S355 J2W EN-10025-5 |
| S355J2W+N EN 10025-5, S355J2W+N EN10025-5, S355 J2W+N EN-10025-5 |
| S355J2G1W EN 10155, S355J2G1W EN10155, S355 J2G1W EN-10155 |
| S355K2G1W EN 10155, S355K2G1W EN10155, S355 K2G1W EN-10155 |
| S355J2G2W EN 10155, S355J2G2W EN10155, S355 J2G2W EN-10155 |
| S355K2G2W EN 10155, S355J2G2W EN10155, S355 K2G2W EN-10155 |
| SAILCOR IRSM41, IRSM-41, IRS-M41 FOR RAILWAY WAGON & CONTAINER |
| JIS G3125 SPA-H, JIS G3125 SPAH, JIS:G3125-SPA-H, JIS-G3125-SPAH, G3125-SPA-H |
Chemical Composition
| Thickness mm Cut lengths | Heavy Plates | C | Si | Mn | P | S | AI | Cr | Ni | Mo | B |
| 3 - 12 | 5 - 30 | 0.20 | 0.70 | 1.70 | 0.030 | 0.015 | 0.060 | 1.50 | 0.40 | 0.50 | 0.004 |
| --- | (30) - 60 | 0.24 | 0.70 | 1.70 | 0.030 | 0.015 | 0.060 | 1.00 | 0.70 | 0.50 | 0.004 |
Mechanical Properties
| Thickness mm Cut lengths | Heavy plates | Yield strengthRp0,2 N/mm2 | Tensile strength Rm N/m2 |
Elongation A5 % |
Hardness range HBW |
Impact strength t0C KV J |
| 3 - 12 | 5 - 15 | 1000 | 1250 | 10 | 360 - 420 | -40 40 |
| -------- | (15) - 30 | 1000 | 1250 | 10 | 380 - 450 | -40 20 |
| -------- | (30) - 60 | 1100 | 1400 | 8 | 380 - 480 | -40 20 |
Equivalent Specifications
Material # |
EN 10155 | SEW 087 | NFA 35-502 | UNI | BS 4360 | ASTM |
|
|
1.8961 |
S235J2W |
WTSt 37-3 |
E 24 W 4 |
Fe 360 DK 1 |
- |
- |
- |
|
1.8945 |
S355J0WP |
E 36 WA 3 |
Fe 510 C1K1 |
WR 50 A |
- |
- |
- |
|
1.8946 |
S355J2WP |
- |
E 36 WA 4 |
Fe 510 D1K1 |
- |
A 242 Type 1 |
- |
|
1.8959 |
S355J0W |
- |
E 36 WB 3 |
Fe 510 C2K1 |
WR 50 B |
A 588 - A 242 Gr. 1 |
SMA 50 AW |
|
1.8963 |
S355J2G1W |
WTSt 52-3 |
- |
Fe 510 D2K1 |
WR 50 C |
A 588 Gr. A |
to |
|
1.8965 |
S355J2G2W |
- |
- |
- |
- |
- |
SMA 50 CP |
|
1.8966 |
S355K2G1W |
- |
E 36 WB 4 |
- |
- |
A 709 Gr. 50 W |
- |
|
1.8967 |
S355K2G2W |
- |
- |
- |
- |
- |
- |
